Zero Scale Pit
Danieli offers the innovative solution of ZSP ™ - Zero Scale Pit technology to replace the standard conventional scale pit with reduction of civil works and execution time and simplify the access and maintenance of the pit.
The tangible advantages are saving of excavations, less civil concrete, less capex investment, fast project schedule and simplified maintenances activities.
The tangible advantages are saving of excavations, less civil concrete, less capex investment, fast project schedule and simplified maintenances activities.
ZSP solution |
Conventional scale pit system |
| Waters coming from the direct cooling of rolling mill line are separated as different fluxes: fluxes containing big/heavy scale are sent to scraper conveyor packages while flux containing only small/ light scale is collected in a separate pit and pumped directly to the longitudinal clarifier. |
All waters coming from the direct cooling of rolling mill line are sent to the scale pit to allow the big/ heavy scale separation. |
| The scraper conveyor packages and the pumping pit are located under/next to the rolling mill, consequently the concrete works are not so depth (-5 / -7 m). |
The scale pit unit collecting all water from contact circuits is located outside the building, because of the depth required (-10 / -15 m). |
| The scale is removed continuously by the chain scrapers of the Dan-Dredge™. |
The scale accumulated in the pit is removed periodically by an automatic bucket. |
| Time required for the execution of civil works is limited (about one month). |
Time required for the execution of civil works is considerable (about six months). |
